Model |
CV-PT35 |
|
Rotating Speed |
Pan:0.01º~60º/s, Tilt:0.05º~20º/s |
|
Rotation Angle |
Pan:0º~360º continuous,Tilt:+45º~ -45º |
|
Number of Presets |
200 |
|
Positioning and Re-positioning Accuracy |
±0.1º |
|
control mode |
Standard motor |
|
Protocol |
Pelco-D/P |
|
Baud Rate |
2400/4800/9600/19200bps |
|
Interface |
RS485 |
|
Input Voltage |
DC28V |
|
Power Consumption |
≤110W |
|
Operation Temperature |
Temp:-35℃~ +70℃ |
|
Storage Temperature |
-40℃~ +75℃ |
|
Max Load |
≤35 kg |
|
Load Mode |
Top-mounted |
|
Temperature Range |
-35 °C +70 °C |
|
Driven |
Worm gear driven |
|
Protection Class |
IP66 |
|
Weight |
23 kg |
